Description
Cnc Weeke Vantage 43M 4 x 10 pieds
Année: 2015
600 volts
-Working field X: 3130mm (123″)
-Working field Y: 1250mm (49.2″)
-Working field Z: 125mm (4.9″)
-Travel range X: 3945mm (155.3″)
-Travel range Y: 1953mm (77″)
-Travel range Z: 340mm (13.4″)
-Two field operation
-Alternating operation
-Vector speed X: 80 m/min
-Vector speed Y: 80 m/min
-Vector speed Z: 20 m/min
-12 vertical drilling spindles
-6 horizontal drilling spindles
-12 HP (9kW) HSK routing spindle
-C-axis 360°
-Grooving saw: 125mm diameter, (0°-90°)
-Compressed air connection: R 1/2 Zoll
-Compressed air required: 7 bar
-Dust extraction port: 200mm
-Dust extraction volume: minimum 3170 m3/h
-Setup dimensions length: 5830mm (229.5″)
-Setup dimensions width: 4100mm (161.4″)
-Setup dimensions length: 2240mm (88.2″)
-Switch cabinet dimension L x W x H: 800 x 800 x 1970
-Weight: 3800 kg
Excellente condition
Machine a Toronto
