Strato planeur EXTEND LIGHT GY-610-S

Strato planeur EXTEND LIGHT GY-610-S – Image 2

Strato planeur EXTEND LIGHT GY-610-S – Image 3

Strato planeur EXTEND LIGHT GY-610-S

Imprimer

UGS : 3843 Catégorie : Strato Planeur

Description

Description

Strato planeur Extend Light Machinery

Modèle: GY-610-S

Année : 2003

600 volts 3 phases

24″ x 8″ Cap., min. material length 12-1/2″ and min. thickness 3/8″.

Equipped with:

•	25 HP Top & 20 HP Bottom belt drive motors.
•	Helical Spiral cutterheads that rotate @ 4,600 RPM; (6) rows or spirals of 4-sided carbide inserts 15 mm x 15 mm.
•	Variable feed speed from: 20 – 95 FPM; powered by: 3 HP drive to lower feed rolls & upper feed mat.
•	Infeed table: Hard chrome plated for max. wear resistance; relieves upper feed mat with spring-loaded spikes; allows cupped bowed or warped boards to feed into the heads for max. straightening capability.
•	Powered lowering & raising of bed table on: (4) Columns via a 1 HP motor; handwheel for fine adjustment of thickness control. Includes
•	Spiral cutterheads; digital control for accurate thickness setting.
•	Side-mounted electrical control & Operator Panel.
•	Automatic feed chain tensioning.
•	Staggered upper infeed fingers to eliminate small part jambs.

#3843
