Description
Emballeuse Phoenix automatique rotative
Modèle PRTA 2200
Voltage 208 3 phases
Convoyeur 3 sections
Besoin d’une réparation un gear box à changer.
Maximum Load Weight: Unlimited (Limited only by conveyor capacity, typically 4,000 lbs (1815 kg))
| Production Capacity: | Up to 80 pallets per hour |
| Wrapping Speed: | 25 RPM |
| Standard Load Weight: | Conveyor Capacity |
| Standard Load Size: | 52″W x 52″L x 80″H |
| Frame Type: | Gantry |
| Standard Film Width: | 20″ |
| Standard Pre-Stretch: | 245% |
| Control System: | AB PLC with HMI |
| Enclosure: | NEMA 12, cUL |
| Standard Electrical Requirements: | 208 VAC / 3 PH / 60 HZ |
| Pneumatic Requirements: | 3 CFM @ 80 PSI |
